ATENVideo Cable Adapters
VGA EDID Emulator
- Subsitutes as a monitor at the site where the computer/video source is located
- EDID built-in - Stores ATEN standard EDID information in device
- ATEN standard EDID supports all popular resolutions
- Superior video quality - up to 1920 x 1200@60Hz, 1366 x 768@60Hz
- USB Powered - No need for an external power adapter
- No software required - Eliminates incompatibility and installation issues; no need to confi gure
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The 2A-130G VGA EDID Emulator is designed for ATEN KVM extender or video extender installations that do not utilize a local monitor at the site where the computer/video source is located. The 2A-130G emulates and stores a default ATEN EDID (Extended Display Identification Information) setting in a non-volatile memory. This means the computer/video source can still "see" the display, even though it is not directly connected.
The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.
Specifications
Features
- Connector 1 form factor
- Straight
- Connector 2 form factor
- Straight
- Cable length
- 0.35 m
- Connector 1
- USB Type-A
- Connector 2
- VGA (D-Sub)
- Connector 1 gender
- Male
- Connector 2 gender
- Male
- Maximum resolution
- 1920 x 1200 pixels
- Supported graphics resolutions
- 1366 x 768, 1920 x 1200 (WUXGA)
- Maximum refresh rate
- 60 Hz
- Product colour
- Blue, Silver
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Weight & dimensions
- Weight
- 40 g
- Width
- 34 mm
- Depth
- 65.9 mm
- Height
- 16 mm
Packaging data
- Package width
- 205 mm
- Package depth
- 245 mm
- Package height
- 20 mm
- Package weight
- 52 g
Logistics data
- Master (outer) case net weight
- 1.6 kg
- Harmonized System (HS) code
- 84733080
- Master (outer) case width
- 212 mm
- Master (outer) case length
- 235 mm
- Master (outer) case height
- 350 mm
- Master (outer) case gross weight
- 2.61 kg
- Products per master (outer) case
- 40 pc(s)
