ThunderboltEX 4 interface cards/adapter Internal Mini DisplayPort, PCIe, Thunderbolt, USB 2.0, USB
- Intel®-certified Thunderbolt™ 4 add-on card
- 40 Gbps bi-directional bandwidth for superfast data transfers and video output
- Dual Thunderbolt™ 4 ports (USB-C®), with support for up to five Thunderbolt devices in a daisy chain
- DisplayPort™ 1.4 for 8K Ultra HD support
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Enable blisteringly fast speeds and any-way-up connectivity
ASUS ThunderboltEX 4 is a Thunderbolt™ 4 add-on card that offers 40 Gbps bi-directional bandwidth, USB4™ device compatibility, and DisplayPort™ 1.4. It supports up to five Thunderbolt devices in a daisy chain and enables up to 100-watt USB-C® charging for laptops.
Specifications
Ports & interfaces
- Host interface
- PCIe
- Output interface
- Mini DisplayPort, PCIe, Thunderbolt, USB 2.0, USB 3.2 Gen 2 (3.1 Gen 2)
- Expansion card standard
- PCIe 3.0
- USB 2.0 ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 2
Design
- Internal
- Yes
- Product colour
- Black
- Purpose
- PC
Features
- Chipset
- Intel Thunderbolt 4 JHL8540
- Data transfer rate (max)
- 40 Gbit/s
- Plug and Play
- Yes
System requirements
- Windows operating systems supported
- Windows 10 x64
Weight & dimensions
- Width
- 117.7 mm
- Depth
- 180.5 mm
Packaging data
- Quantity
- 1
- Cables included
- Mini DisplayPort, Thunderbolt, USB
- Drivers included
- Yes
- Manual
- Yes
- Package type
- Box
Logistics data
- Harmonized System (HS) code
- 84733020
Other features
- Maximum resolution
- 7680 x 4320 pixels
- Compatibility
- ASUS Intel 500
