ASUS RT-BE96U Drag to turn · 7 views
ASUSWireless Routers

BE19000 wireless router 10 Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 6 GHz) Black

Part # RT-BE96UUPC 1971052488619 lb

  • Next-gen WiFi Standard – Beyond-fast WiFi 7 (802.11be) with new 320MHz channels in the 6 GHz band and 4096-QAM significantly increases network capacity and throughput, with speeds of up to 19 Gbps
  • Multi-link Operation – Links to multiple bands at the same time to ensure stable internet connections and efficient data transfers
  • Dual 10 Gbps Ports – Maximized wired connectivity and flexible network port configuration for ultra-fast backhaul applications with dual 10G ports
  • Subscription-free Network Security – With commercial-grade AiProtection Pro powered by Trend Micro™, plus a one-tap security scan and Safe Browsing
  • Advanced Parental Controls – Protect your kids online with instant monitoring, content filters and customized settings for every connected device
  • Comprehensive VPN Features – Including the Instant Guard mobile app for secure connection over public WiFi
Special orderPrice on request
View quote list
  • Reply within 1 business day
  • Volume & business pricing
  • Shipping across Canada & US

Overview

BE19000 Tri-band WiFi 7 Router, support new 320MHz bandwidth & 4096-QAM, Multi-link operation (MLO), dual 10G ports, subscription-free network security and comprehensive VPN features

01

WiFi 7 – 2X Higher Capacity

WiFi 7* introduces all-new ultrawide 320 MHz channels**, doubling data transmission capacity. You can think of networking as a virtual freeway and the doubled bandwidth as a doubling of the number of lanes. Now larger vehicles are allowed to get on the freeway and can pack more data than ever before.

02

Future-proof Your Connected Homes

The tri-band RT-BE96U offers 6 GHz, 5 GHz and 2.4 GHz WiFi networking, with speeds of up to 19Gbps*. This solution ensures comprehensive WiFi compatibility for all your devices, from cutting-edge mobile devices to legacy smart home products with long lifespans. With ASUS AiMesh technology, it's easy to combine RT-BE96U with multiple ASUS extendable routers to create a seamless mesh network with rich, advanced features.

03

Reliable WiFi with Multi-Link

Before WiFi 7, transmissions were limited to one band, such as 2.4 GHz or 5 GHz. Multi-Link Operation* (MLO) allows a device to simultaneously connect on multiple bands, enabling faster speeds by aggregating bandwidth, with more reliable WiFi connections on multiple concurrently used bands. Connecting to multiple bands in this manner also enables seamless switching — a process that automatically allocates data to the most suitable band, to reduce latency.

RT-BE96U sending out one 5GHz band and one 6GHz band, two bands aggregates with simultaneous MLO technology for larger bandwidth, while 5GHz band and 6GHz combing into one with alternating MLO technology for seamless switch. Two bands received by smart phone, smart phone is connected to 5GHz and 6GHz band simultaneously.

04

Flexible Network Port Configuration

The RT-BE96U’s dual 10 Gbps ports make it a great choice for servers or NAS devices. These are more convenient than simply combining multiple gigabit Ethernet ports, and they help increase your available bandwidth to avoid data bottlenecks throughout your whole network. Users are also empowered to leverage multiple high-speed internet service providers.

05

Cool and Stable

The RT-BE96U is engineered to deliver maximum WiFi performance. The increased clearance under the router is designed to improve airflow through the vents, complementing the quadruple heatsink for even greater reliability.

06

Subscription-Free Network Security

Home network security is crucial when you have multiple connected devices. It’s even more important when there are components without anti-virus capabilities such as IoT devices. RT-BE96U provides commercial-grade AiProtection powered by Trend Micro™, your home network is automatically shielded with up-to-date protection against internet threats.

Specifications

WAN connection

Ethernet WAN
Yes
SIM card slot
No
3G/4G USB modem compatibility
Yes

Wireless LAN features

Wi-Fi band
Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)
11529 Mbit/s
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
WLAN data transfer rate (first band)
1376 Mbit/s
WLAN data transfer rate (second band)
5764 Mbit/s
WLAN data transfer rate (third band)
5764 Mbit/s
WLAN data transfer rate (fourth band)
11529 Mbit/s

Network

Ethernet LAN
Yes
Ethernet LAN interface type
10 Gigabit Ethernet
Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s
Dynamic DNS (DDNS)
Yes
Support Samba (storage)
Yes
Built-in FTP server
Yes
Media server
Yes
VPN support
VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion

Ports & interfaces

Ethernet LAN (RJ-45) ports
6
USB port
Yes
USB 2.0 ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1

Management features

Quality of Service (QoS) support
Yes
Wake-on-LAN ready
Yes
Reset button
Yes
WPS push button
Yes
MU-MIMO technology
Yes

Security

Security algorithms
SSH, WPA-Enterprise, WPS
Firewall
Yes
Parental control
Yes
MAC address filtering
Yes
System event log
Yes
DMZ support
Yes

Protocols

DHCP server
Yes

Design

Product colour
Black
LED indicators
LAN, Power, WAN
On/off switch
Yes
Product type
Tabletop router

Packaging content

Cables included
LAN (RJ-45)
AC adapter included
Yes
Warranty card
Yes
Quick start guide
Yes

Antenna

Antenna design
External
Antennas quantity
8

Features

Built-in processor
Yes
Internal memory
2000 MB
Flash memory
256 MB

Power

Power source type
AC
AC input voltage
110 - 240 V
AC input frequency
50/60 Hz
Output voltage
19.5 V
Output current
3.33 A

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
0 - 70 °C
Operating relative humidity (H-H)
50 - 90%
Storage relative humidity (H-H)
20 - 90%

Weight & dimensions

Width
350.6 mm
Depth
350.6 mm
Height
217.6 mm
Weight
1.87 kg
