Home/Catalogue/ASUS/PRIME-RX9070XT-O16G-WHITE
Drag to turn · 12 views
ASUSGraphics Cards
Prime -RX9070XT-O16G-WHITE AMD Radeon RX 9070 XT 16 GB GDDR6
- AMD Radeon RX 9070 XT 16 GB GDDR6
- 7680 x 4320 pixels 256 bit 20 Gbit/s PCI Express 5.0
- HDMI ports quantity: 1 DisplayPorts quantity: 3
- OpenGL version: 4.6
- 3x 8-pin
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
ASUS Prime Radeon™ RX 9070 XT White OC Edition 16GB GDDR6 boasts three axial-tech fans and a phase-change GPU thermal pad for supreme cooling.
Specifications
Processor
- CUDA
- No
- Graphics processor family
- AMD
- Graphics processor
- Radeon RX 9070 XT
- Processor frequency
- 2460 MHz
- Processor boost clock speed
- 3010 MHz
- Processor frequency (OC mode)
- 2480 MHz
- Processor boost clock speed (OC mode)
- 3030 MHz
- Maximum resolution
- 7680 x 4320 pixels
- Parallel processing technology support
- Not supported
- Stream processors
- 4096
- Maximum displays per videocard
- 4
Memory
- Discrete graphics card memory
- 16 GB
- Graphics card memory type
- GDDR6
- Memory bus
- 256 bit
- Data transfer rate
- 20 Gbit/s
Ports & interfaces
- Interface type
- PCI Express 5.0
- HDMI ports quantity
- 1
- HDMI version
- 2.1b
- DisplayPorts quantity
- 3
- DisplayPort version
- 2.1a
Performance
- OpenGL version
- 4.6
- HDCP
- Yes
- HDCP version
- 2.3
- Dual Link DVI
- No
- Overclocked (OC) edition
- Yes
Design
- Cooling type
- Active
- Cooling technology
- ASUS Axial-tech
- Number of fans
- 3 fan(s)
- Form factor
- Full-Height/Full-Length (FH/FL)
- Bracket height
- Full-Height (FH)
- Number of slots
- 2.5
- Illumination
- No
- SFF ready
- No
- Product colour
- White
Power
- Minimum system power supply
- 750 W
- Supplementary power connectors
- 3x 8-pin
System requirements
- Windows operating systems supported
- Yes
Weight & dimensions
- Weight
- 1.16 kg
- Length
- 312 mm
- Depth
- 50 mm
- Height
- 130 mm
Packaging data
- Package width
- 405 mm
- Package depth
- 233 mm
- Package height
- 88.5 mm
- Package weight
- 1.75 kg
- Package type
- Box
